WS202-868M

€59,50
SKU WS202-868M

Specifications

Wireless Transmission Technology LoRaWAN®
Frequency CN470/IN865/RU864/EU868/US915/AU915/KR920/AS923
Tx Power 16 dBm (868 MHz)/22 dBm (915 MHz)/19 dBm (470 MHz)
Sensitivity -137 dBm @300bps
Mode OTAA/ABP Class A
Measurement PIR Detection Area 120 ° Horizontal, 100 ° Vertical
Detection Distance Maximum 8 m
Light Status Bright/Dark (Determine 1-60000 lux as Bright or Dark according to custom threshold)
Operation Configuration NFC Configuration via Mobile App
Physical Characteristics Power Supply 1 × 1650 mAh ER14335 Li-SOCl2 battery
Battery Life* Built-in 1650 mAh battery to use for around 4 years with 30 triggers per day
Operating Temperature -30°C to +60°C
Relative Humidity ≤90% (non-condensing)
Ingress Protection IP30
Dimension 50 × 50 × 23.8 mm (1.97 × 1.97 × 0.94 in)
Material Anti-flaming Polycarbonate
Color White
Installation On the flat surfaces with screws or 3M tapes
