VS121-868M-W

€337,88
SKU VS121-868M-W

 Specifications

LoRaWAN® Protocol LoRaWAN® v1.0.2/v1.0.3/v1.1
Frequency CN470/IN865/RU864/EU868/US915/AU915/KR920/AS923
Tx Power 16 dBm (868 MHz)/22 dBm (915 MHz)/19 dBm (470 MHz)
Sensitivity -137 dBm @300bps
Mode OTAA/ABP Class C
People Counting Field of View 112 ° Horizontal, 190 ° Vertical
Detection Range 5 m radius or 78 m² (At the height of 3 m)
Detection Accuracy >95%
Advanced Custom Setting Up to 12 mapped regions for detection
Interface Wi-Fi IEEE 802.11b/g/n, 2.4 GHz, only support configuration
Button 1 × Reset Button, 1 × Wi-Fi Button
LED Indicators 1 × Wi-Fi
Power Input 1 × Type-C
Physical
Characteristics
Power Supply 5V / 1.5A by Type-C Port
Operating Temperature -5°C ~ +55°C
Storage Temperature -20°C ~ +60°C
Relative Humidity 0 ~ 95% (Non-condensing)
Color Black/White (Optional)
Dimension 85 × 85 × 20 mm (3.35 × 3.35 × 0.79 in)
Installation Ceiling Mounting
