WD7-001-01 Touch Screen Display for ALL HTML 5 Building Management Systems, example: Niagara 4 Jace, TONN, Hawk, EC-BOS (3, 6 & 8000), Niagara 4 PC Supervisors from Tridium, Distech (EC-NET), Honeywell Centraline (Arena) or Trend (IQ Vision).
About the product
This is the most innovative display specifically designed for the Building Management Industry and Industrial Applications. This high quality. wall mounted, touch screen display has been designed to work with any Jace 3,4,8000, Distech Controller, Honeywell Centraline and in fact with any HTML5 serving BMS.
This award winning design allows you to easily connect to the BMS controller via WIFI or Ethernet Cable and is ideal for retrofit and new builds.
- Display Resolution: 1024x600 pixels
- Dimensions (outer dimensions when mounted in own frame): 234.22mm x 127mm x 18.5mm - 9.22 x 5 x 0.73 inches
- Screen Size (Diagonal): 177.8mm - 7.0 inches
- Touch Panel: COB, Support 5 points touch
- CPU / GPU: RK3126 Cortex-A7 Quad Core 1.2GHz / Mali 400 MP2
- Memory DDR / Flash / Removable: 512MB / 4GB / Removable microSD Card up to 32GB
- Operating System / Preinstalled Software: Android 6.01
- Operating temperature range: 0°C to 40°C
- Enclosure protection: IP 40
- Wireless Support: WiFi b/g/n - Bluetooth 4.0
- EMI Compliance: CE, FCC, ROHS
- Battery Type: Polymer Lithium Battery, 2400mAh/3.7V
- Connect to Internet: WiFi or Ethernet (using the supplied USB adaptor)
- Loudspeaker / Mic: YES / YES - Built in
- Power Supply
- Rating: 10W Switched Mode Power Supply
- Input / Output Voltages: 90-264V AC / 5V DC
- Wired Connections: Un-terminated wire for spur connection / O/P 2.5mm barrel Connection
- Power Supply Frequency Hz: 50-60 Hz
- Dimensions: 82.5mm x 40mm x 29mm (Fits inside electrical back box as shown below)
Documentation & Downloads
|WD7-001-01 Installation Instruction|
||WD7-001-01 7inch-Display-Drill-and-Dimensions V1.0|
||WD7-001-01 7inch-Release Note 2.18|
||WD7-001-01 7inch-DisplayUpdate Procedure|
